Wall-mount RGBW Controller with touch panel White

Article number: 000225
Availability: In stock
Delivery time: Shipped within 24 hours

White wall touch panel dimmer for RGBW LEDStrips. Thanks to the glass panel, this wall dimmer looks great in any interior, and is easy to clean. We also sell an RGB, Dual color and Single color Touch panel in this design. Please see "related products".

This touch panel dimmer contains a few useful extra functions, which include:
- 20 Seconds delay when switching off, allowing you to leave the room.
- Possibility to save a number of presets.
- The buttons light up in the dark.

The wall dimmer is connected between the 12V / 24V power supply and the LED strip. The max. output power of this dimmer is 4x4A. This means that you cannot connect more than 192W at 12V and 384W at 24V. If you want to control more LED strip with this dimmer, please use repeaters or contact us for help.

Color: White
Easy connections.
In/output voltage: 12-24V DC
Output: 4x CMOS output
Memory (remembers last setting when power is shut off): Yes
Connecting mode: Common Anode (+)
Rated current: 4A for each Channel (Max total power: 192 Watt at 12V or 384 Watt at 24V)
Working temperature: -20 to 60 Degrees Celsius (-4 to 140 degrees Fahrenheit)
Size: Length 86mm x Width 86mm x Depth 35mm
Min. size of installation hole: H66mm x W60mm
