Power supply 120W Waterproof HLG-120H-54AB

Article number: HLG-120H-54AB
Availability: In stock
Delivery time: Shipped within 24 hours

Meanwell HLG-120H-54AB
IP67 Waterproof Constant-Current Power Supply for our LED Growlights 100W. (See related products).
Meanwell HLG Series Power supply: With these power supplies you are assured of a quality product that meets all European standards. These adapters are safe, reliable, and specially developed for LED Applications such as horticulture.
Both the input and the output of this power supply are finished with only wire.

Amperage: 2300mA Max.
Dimmable: Yes, 3-in-1 dimming: 1-10V, 10V PWM or resistor

How to connect:
Connect one 100W 2100mA LED Growlight to this power supply.
Important: This power supply is supplied from the factory with the current set to 2300mA. Use the potentiometer on the power supply to lower the current to max. 2100mA.


Downloads:
Datasheet HLG120H

Details:
Output power: 120 Watt
Output voltage: 27-54V
Amperage: 2300mA Max.
Input voltage: 100-240 Volt AC 50/60Hz
Brand: Meanwell
Article code: HLG-120H-54AB
Waterproof: Yes (IP67)
Warranty: 8 Years
Dimensions: 220mm *68mm * 38.8mm
